WebSSH

SSH access via the browser

WebSSH lets you open an SSH session to any node directly from the browser. It uses a Go-based WASM shim that creates an ephemeral Tailscale node in the browser and connects to the target node over the Tailnet.

Prerequisites

• Headscale 0.28 or newer is required.
• Target nodes must have Tailscale SSH enabled.
• Users must be authenticated via OIDC (API key logins cannot use WebSSH).
• The Headplane Agent must be enabled and configured so that ephemeral node cleanup works correctly.
• The WASM assets (hp_ssh.wasm and wasm_exec.js) must be present in the build. These are built automatically by ./build.sh --wasm.

How It Works

When a user opens an SSH session from the UI, the browser:

1. Loads a Go WASM binary that implements a minimal Tailscale node.
2. Authenticates to the Tailnet using an ephemeral pre-auth key generated server-side.
3. Connects to the target node over the Tailnet using DERP relay servers.
4. Opens an SSH session and renders it in an xterm.js terminal.

The ephemeral node is automatically cleaned up after the session ends.

DERP Servers on Non-Standard Ports

In the browser, Tailscale connects to DERP relay servers via WebSockets. If your DERP servers run on a non-standard port (e.g. :8443 instead of :443), Headplane includes a patch to Tailscale's DERP client that preserves the port in WebSocket URLs. This patch is applied automatically during the WASM build.

::: warning If you are building the WASM module manually (outside of build.sh), make sure to apply patches/tailscale-derp-port.patch to the vendored Tailscale source before compiling. See the build_wasm() function in build.sh for reference. :::

Troubleshooting

"WebSSH is not configured in this build"

The WASM assets are missing. Rebuild with ./build.sh --wasm or ensure your Docker image was built with the --wasm flag.

"Only OAuth users are allowed to use WebSSH"

WebSSH requires OIDC authentication to generate pre-auth keys tied to a Headscale user. API key logins do not have an associated Headscale user identity.

Connection hangs or fails to reach the node

• Verify that the target node has Tailscale SSH enabled.
• If using custom DERP servers on non-standard ports, ensure you are running a build that includes the DERP port patch (any build from build.sh or Docker includes it automatically).
• Check the browser console for WASM errors or DERP connection failures.
