Headplane Agent
The Headplane Agent is an optional component that can be enabled on your Headplane instance in order to unlock additional features such as remote web-based SSH and detailed machine information.
Configuration
To enable the Headplane Agent, you'll need to modify the following fields in your Headplane configuration file. For more information on configuring Headplane please refer to the example configuration for details.
| Field | Description |
|---|---|
integration.agent.enabled |
Set to true to enable the agent. |
integration.agent.pre_authkey |
A reusable pre-auth-key (see below). |
integration.agent.host_name |
Optional. Host name to register as. |
integration.agent.cache_path |
Optional. Cache path for the agent. |
integration.agent.work_dir |
Optional. Working directory for the agent. |
Native Mode Configuration
Once you've built Headplane locally, there will be a binary in the ./build
folder called hp_agent. Please move this binary to
/usr/libexec/headplane/agent and ensure that it is executable.
::: tip
If for some reason you cannot move the binary to the intended location, you can
define integration.agent.executable_path in your Headplane configuration
file to point to the correct location of the agent binary.
:::
The agent will also use /var/lib/headplane/agent as its data directory by
default. You can change this location by defining
integration.agent.work_dir in your Headplane configuration file. Ensure
that the specified directory exists and is writable by the user running
Headplane.
Usage
After enabling and configuring the Headplane Agent, restart your Headplane instance. You should now see additional options in the UI, such as host information about each node and the ability to open SSH sessions directly from the browser if the nodes have Tailscale SSH enabled.
